Falcon W561PD HANA Classroom Knob Lock

Usually Ships: 1-2 Business Days
  • Certified ANSI/BHMA A156.2, Grade 2
  • ANSI Function F84 – Classroom
  • UL listed, 3 hour fire-rated

Available Options:

Clear

Falcon W561CPD HAN Grade 2 Classroom Cylindrical Lock, Schlage C Keyway, Hana Knob, Standard Rose

The Falcon W Series offers a quality product at a value price, and is backed by one of the best names in the business – Allegion.

ANSI Function F84 – Deadlocking latch bolt by knobs. Outside knob is locked by key in outside knob. Inside knob is always free.

Knobs are constructed of brass or cold-formed steel and are zinc-plated and dichromated for rust resistance. Springs are stainless steel. Roses are heavy-wrought brass or bronze, installed over wrought steel reinforcing plates. Knobs are brass or bronze, secured by a steel knob retainer, which cannot be depressed when lock has been locked.

Brand

Finishes

613 Oil Rubbed Bronze, 626 Satin Chrome

Lock Function

Classroom

Cylinder & Keys

6-pin conventional, keyed different, with 2 keys

Keyway

Schlage C Keyway

Usage

Medium Duty

ANSI/BHMA Standard

Tested and certified under ANSI/BHMA A156.2, Grade 2

Fire Rating

UL/cUL listed up to 3 Hours – UL symbol on the latch front

Latch

1/2” throw, deadlocking – 1-1/8" x 2-1/4" face

Backset

2-3/4"

Strike

4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation

Handing

Non-Handed

Door Thickness

1-3/8" to 1-3/4"

Warranty

10 Year Limited
