TGP FireLite® NT Fire-Rated Safety Glass Ceramic, 90-Minute Labeled, Cut-to-Size

TGP FireLite® NT Cut-to-Size 90-Minute Fire-Rated, Safety-Rated Glass Ceramic with Surface-Applied Film for Windows and Doors

FireLite NT is a 3/16” (5 mm) thick fire-rated and impact safety-rated glazing material, composed of FireLite and fire-rated surface-applied film. It is listed for use in doors, sidelites, transoms and borrowed lites.

TRUDOOR® is certified by UL to cut, re-certify, and label TGP FireLite® NT glass and fire-protection-rated glazing materials.

• Applications: Door vision lites, borrowed lite window frames, sidelites, and transom lite frames
• Wireless glass ceramic with high performance surface-applied approved fire-rated film
• ultraHD® Technology for improved surface quality, clarity and color
• Impact safety-rated–meets ANSI Z97.1 and CPSC 16 CFR1201 (Cat. I and II)
• Withstands thermal shock
• Protects from fire and impact on both sides of the glass
• Standard Grade – Polished for a surface quality that is comparable to alternative fire-rated ceramics marketed as having a premium finish.
• Classified and labeled by Underwriters Laboratories, Inc.®
• Each piece of FireLite NT shall be permanently labeled with the FireLite NT logo, UL logo, and fire rating (90 Minutes with Hose Stream)
• Can also be used with applications that require 20 minute, 45 minute, or 60 minute fire-rating
• Largest Sheet Size: 49″ x 82″

FireLite® NT fire glass with 3-hour certification in limited sizes available.

FireLite is made from transparent glass-ceramic which appears to have a warmer earth tone when compared to the blue-green tint of typical float glass. Like float glass, FireLite ceramic will not demonstrate a highly perceptible color once installed in a frame. FireLite also features ultraHD® Technology, for improved color, clarity, and surface quality.

LISTINGS

Classified and labeled by Underwriters Laboratories, Inc.® and Underwriters Laboratories of Canada. File number for labeled fire-rated assemblies is UL File No. R13377. Tests performed in accordance with: UL9, UL10B, UL10C, NFPA80, NFPA252, NFPA257, CAN/ULC-S104, CAN/ULC-S106, MEA 290-90-M-6, LARR 25798

Check with frame manufacturer for maximum tested glass sizes and required stop height. All listing information is subject to change. Note: This product is not a barrier to radiant heat, as it does not meet test standards ASTM E119 or UL 263.

Labeling: After cutting, each piece of FireLite NT shall be permanently labeled with the FireLite NT logo, UL logo, and fire rating.

Please refer to IBC code Chapter 7 (International Building Code) for fire-rated glass requirements and limitations. Frame, door, and/or hardware must also be fire-rated. Fire-rating requirements must match the glazing requirements in order for the assembly to fully meet code requirements. Please refer to manufacturers’ specifications. Please Consult with your door and frame manufacturer’s procedures, for their maximum glass size tested. Interpretation of building and fire codes may vary. Consult with the local authority having jurisdiction to determine appropriate standards in your area. Trudoor assumes no liability or responsibility for any damage to person or property resulting from or incident to the use of the products that we provide. Trudoor assumes no liability or responsibility for misspecified and/or misordered materials. Glass is cut to order and non-returnable or refundable.

Trudoor is certified by UL to cut, re-certify and label fire-rated glazing materials. Our facility undergoes routine inspections to verify that modifications are done in compliance with the requirements of the UL specification listings. All material is tested in accordance with NFPA codes and standards.

FireLite® is a registered trademark of TGP

Installation

FireLite NT shall be glazed into the appropriate fire-rated framing with an approved glazing compound (closed cell PVC tape or DAP 33 putty) as supplied by the installer. For 90 minute ratings that exceed 1,393 in2 (.8987 m2), FireLite NT shall be glazed with fire-rated glazing tape as supplied by TGP. Inspect each piece of FireLite NT immediately before installation and eliminate any with observable edge damage or face imperfections. As with any glass produced by the “roll out” method, individual pieces of FireLite NT may contain minimal variations in thickness. Occasionally, process marks and small occlusions or seeds (bubbles, knots or crystals) may be apparent. However, since they do not generally impair the transparency or affect the technical performance of the glass, they do not represent cause for rejection.

Storage and Handling

FireLiteNT must be handled with care during transportation, storage, inspection and installation. Store in a dry place.

Glass is cut to order and non-returnable or refundable.

Call 1-844-TRUDOOR (844-878-3667) for info on volume discounts
