Markar-HG305-Hinge
HG305
Markar-HG305-Hinge
HG305

Markar HG305 Adjustable Hinge Guard, Stainless Steel Pin & Barrel Continuous Hinge, Double Return

Usually Ships: 1-2 Business Days
  • Heavy-duty 14 gauge stainless steel
  • Supports weights up to 600lbs
  • Integral hinge guard protects the door

Available Options:

Clear

Product Overview

Markar HG305 Adjustable Hinge Guard, Stainless Steel Pin & Barrel Continuous Hinge, Double Return

The Markar HG305 Hinge Guard protects your door from dings and gouges from carts and gurneys, while providing clean lines and aesthetic appearance. All hinge guard products also have fire ratings up to and including 3 hours.

Features

  • Stainless steel end pins
  • Fasteners concealed when door is closed
  • Supports weight up to 600 lbs., 4’0″ maximum door width
  • Symmetrically templated hole pattern
  • Exterior barrel diameter .438″ (7⁄16″)
  • Fastener screw pack includes Custom 12-24 x 11/16 S.S Phillips Flat Head Undercut TEK Screws

Benefits

  • Protects door from dings and gouges from carts and gurneys
  • Fire ratings up to and including 3 hours
  • Provides clean lines and aesthetic appearance

Certifications

  • ANSI/SDI 250.13 Certified
  • UL 10C positive pressure
  • UL 10C – Standard for Positive Pressure Fire Tests of Door Assemblies
  • Warnock Hersey listing
  • ANSI/BHMA Standard A156.26
Brand

Finish

Stainless Steel
Material

304 Stainless Steel
Usage

Heavy Duty
ANSI/BHMA Standard

ANSI/BHMA Standard A156.26 Grade 1
Fire Rating

UL 10C – Standard for Positive Pressure Fire Tests of Door Assemblies, Warnock Hersey Listing
Continuous Hinge Type

Full Mortise (Concealed)
Buy American Act Compliance

Meets Buy Amercian Act – Made in USA
