Markar FM300 Heavy Duty Full Mortise Edge Mounted Stainless Steel Pin & Barrel Continuous Hinge

Markar FM300 Series Full Mortise Edge Mounted Stainless Steel Pin & Barrel Continuous Hinge, Satin Stainless Steel

The Markar FM300 Series Full Mortise Continuous Pin and Barrel Hinge is edge-mounted and used on high traffic, high abuse doors. This hinge is ideal in locations that would normally call out for anchor hinges, pivot reinforcement hinges or thrust pivot unit and hinge sets. Additionally, this hinge saves on special door and frame preparation charges and can be used on both fire labeled and non-labeled openings.

Features

• Used for high traffic, high abuse doors
• Exterior barrel diameter .438″ (7/16″)
• Fasteners are concealed when door is closed
• Screw pack includes custom 12-24 x 11/16 S.S Phillips flat head Undercut TEK Screws
• Hinges are furnished with hardware pack per specific model application
• Symmetrically templated hole pattern

Benefits

• Provides full height door support
• Saves on special door and frame preparation charges
• Can be used on both fire-labeled and non-fire-labeled openings
• Each knuckle includes nylon bearings for a quiet, smooth, self-lubricating operation
• Used instead of anchor hinges, pivot reinforcement hinges, thrust pivot units
• Easy installation
• Guaranteed for the life of the opening against defects in material or workmanship

Certifications

• ANSI/SDI 250.13 Certified
• ASTM E330 Certified
• Environmental Product Declaration (EPD)
• UL 10C – Standard for Positive Pressure Fire Tests of Door Assemblies
• Warnock Hersey listing
• ASTM E1996 Certified
• ASTM E1886 Certified
• Florida Building Code Approved TAS 201, 202, 203 (old)
• ANSI/BHMA Standard A156.26
• ANSI/BHMA Standard A156.26 Grade 1
