Cal-Royal A7760V x ESC7700 Surface Vertical Rod Exit Device with Escutcheon Entrance Lever Trim

Cal-Royal A7760V/AF7760V x ESC7700 Surface Vertical Rod Exit Device with Escutcheon Entrance Lever Trim, Heavy Duty Grade-1

For use in institutions, schools, universities, and commercial buildings where heavy-duty, reliable operation is a requirement.

• ANSI Function 08 – Rigid Entrance, key locks or unlocks escutcheon trim – Operates as classroom function
• ANSI A156.3, GRADE 1 heavy-duty exit device
• Retrofits Von Duprin 99 & 98 Series using 7700 Escutcheon trim
• Rail assemblies are heavy-duty extruded aluminum body with stainless steel push pad and end caps are made of brass, bronze or stainless steel
• Trims are thru-bolted for additional security
• Conforms & Meets ADA Regulations
• Americans with Disability Act (ADA) Compliant, 5 lbs. opening force
• UL and ULC Listed – A7760V Series for panic. AF7760V Series for fire exit hardware for all types of 8’ x 10’ double doors for up to 3-hour fire labeled installations. Conforms to standards UL10C and UBC 7-2-1997 codes.
• Uncompromising security and safety in single and double fire exit doors
• Chassis-mounted unit construction
• Non-handed and easily reversible

ESC7700 Lever Trim

• 2-3/4″ width x 10-1/4″ length – Lever length: 4-3/4″
• Fits and covers 2-1/8″ 161 cutout
• Rigid, non-clutch mechanism
• Double heavy-duty spring support to prevent sagging and enhance operation
• Grade 1, thru-bolted design.
• Non-handed design – Easily field reversible
• Hardened steel heavy-duty tailpiece
• Includes mortise cylinder (Schlage C keyway)
