Air Louvers VSL Slimline Vision Lite Kit PAK with 1/4″ Frosted Acid Etched Safety Glass

Usually Ships: 5-10 Business Days
  • Complete Lite Kit = Frame, Glass & Glazing Tape
  • Includes acid-etched (frosted) impact-rated safety glass
  • For 1-3/4″ thick steel or wood doors

Available Options:
Clear

Product Overview

Complete Lite Kit Pack – VSL Vision Lite Frame, 1/4″ Thick Acid Etched Safety Glass, and Glazing Tape

Includes glass with an acid treatment that is applied to the face of the glass, resulting in a smooth, translucent surface with a certain degree of opacity.

  • Order size equal to cutout size – Glass size is 1″ under, Visible glass is 2″ under
  • Includes 1/4″ thick acid-etched (frosted) CAT II impact-rated glass (heat-treated safety glass that breaks into small particles)
  • 1-1/4″ trim with radius corners, mitered and welded
  • Continuous glass retainer, countersunk mounting holes in the bevel on the non-corridor side
  • Includes glazing tape

All lite kits are carefully packaged to ensure safe delivery. Due to the weight and/or fragile nature of this product, a handling/package fee will be added upon checkout. The fee varies depending on the shipping destination. See our shipping info page for more details.

Brand

Finishes

Gray (G), Mineral Bronze (B)
Order Size

5" x 35", 6" x 27", 7" x 22", 8" x 32", 8" x 36", 24" x 24", 24" x 30", 24" x 32", 24" x 36", 24" x 60", 24" x 64"
Frame Profile

Low
Frame Construction

20 Gauge Cold Rolled Steel
Glass Type

Frosted Tempered Glass
Glass Thickness

1/4"
Glass Impact Safety Rating

ANSI Z97.1, Class A; and CPSC 16 CFR 1201 Category II
Glass Fire-Rating

None
Glass Appearance

Frosted – ReflectSmooth Surface:2
Glass Approvals

ANSI Z97.1, Class A; and CPSC 16 CFR 1201 Category II
Door Thickness

1-3/4"
