Air Louvers VLF-SG Vision Lite Frame with 12 Gauge Security Grille for 3/16″ to 1/4″ Glass, 1-3/4″ Thick Door

Usually Ships: 20-30 Days
  • 18-gauge steel frame w/ 12-ga. grille on both sides
  • For 3/16″ to 1/4″ glass (not included)
  • For 1-3/4″ thick steel or wood doors

Available Options:

Clear

Security vision lite frame with 12-gauge security grille for 3/16″ to 1/4″ glass, for 1-3/4″ thick doors

  • Mitered and welded corners with countersunk mounting holes
  • Security grille welded to frame, on each side
  • Grille: 12 gauge CRS with 13/16″ square openings 1″ on center
  • Glass / Glazing Tape Not Included – glazing to be ordered separately from our glazing section. Use fire rated glazing with Warnock Hersey (WHI) or UL classification markings for fire-rated applications.
  • Visible light is 2″ under rough opening size. Glass size is 1″ under order size





This product is made to order and non-returnable or refundable.

Call 1-844-TRUDOOR (844-878-3667) for custom sizes and info on volume discounts

Brand

Finishes

Gray (G), Mineral Bronze (B)

Order Size

6" x 27", 8" x 32", 12" x 12", 18" x 18", 24" x 30", 24" x 32", 24" x 36", 24" x 60", 24" x 64"

Construction

18 Gauge Steel Frame w/ 12 Gauge Security Grille

Frame Profile

Standard

Frame Fire-Rating

Up to 90 Minutes. Tested and Listed for UL 10C and Criteria of UBC 7-2 Positive Pressure.

Glass Thickness

3/16" to 1/4"

Door Thickness

1-3/4"

Fasteners

#8-32 Phillips head thu-bolts with blank head one side

Buy American Act Compliance

Meets Buy Amercian Act – Made in USA
