Securitron M380E Magnalock Electromagnetic Lock, 600lb Holding Force

Usually Ships: 3-5 Business Days
  • For single interior doors
  • Energy efficient, low power usage
  • 600 lbs. holding force

Available Options:

Clear

Securitron M380E Series Magnalock, 600lb Holding Force, Bracket Mount, 12/24VDC

Easily installed, bracket mounted Magnalock for interior applications

Intelligent, stylish and secure, with up to 80% reduction in energy consumption over the previous M380 Series

With integrated features such as built-in smart voltage sensing, tamper sensor and an updated strike plate mounting template, the Securitron M380E joins the Securitron M680E in the family of sustainable magnalocks. The Securitron M380EBD and M380EBDX models offer additional integrations, such as Securitron’s patented BondSTAT lock sensor, Door Position Switch, built-in door prop sensing (which allows the magnet to de-energize the coil when the door is held open for extended periods), and a passive infrared request to exit (PIR REX).

Features

  • Sustainability documentation
  • Energy efficient, low power usage
  • Synchronous double door release using a single Request to Exit
  • Auto calibration upon installation
  • Automatic dual-voltage – no field adjustment required
  • LED Indicator shows the lock is secure, open, or has an incomplete bond
  • Tamper Switch sends an alarm output if the cover is removed and is selectable to NO or NC
  • Rust resistant – all ferrous metal surfaces plated for durability
  • Adjustable automatic relock timer (0 to 30 seconds)
  • Wire chamber anti-tamper switch
  • Size optimized for use with door closers
  • Patented BondSTAT lock sensor and integrated Door Position Switch (DPS) with relock timer
  • Optional: X Integrated passive infrared request to exit
  • MagnaCare® lifetime replacement, no fault, no questions asked warranty

Models: M380EBD-628, M380EBD-606, M380EBD-613E, M380EBD-BSP, M380EBDX-628, M380EBDX-606, M380EBDX-613E, M380EBDX-BSP

Brand

Finishes

613e Dark Oxidized Satin Bronze equivalent, BSP Black Suede Powder Coat, US4 (606) Satin Brass, US28 (628) Anodized Aluminum

Electrical

Current 12v DC (mA) : 585, Current 24v DC (mA) : 310, Voltage : 12/24

Holding Force

Up to 600 lbs.

Monitoring

BD: BondSTAT Monitor & Door Position Switch

Fire Rating

ANSI/UL 10C Listed, 3 hour rated
