Schlage L463L Classroom Mortise Deadbolt Lock, Less Cylinder

Usually Ships: 10-15 Business Days
  • Extra Heavy Duty, ANSI Grade-1 Certified
  • Classroom Deadbolt (Cylinder Sold Separately)
  • ANSI Function: E06091

Available Options:


Schlage L463L Grade 1 Small Case Mortise Deadbolt, Cylinder x Thumbturn, Classroom Function, Less Cylinder, Satin Chrome

Nothing is tougher! L400 Series locks are designed for use as primary locks where no latching is required, such as restrooms and small doors to utility spaces. They also offer optimum security when used as auxiliary locks in other applications. Schlage L Series Extra Heavy Duty Mortise Locks are built to withstand the rigors of daily use without fail.

ANSI Function E06091 – Deadbolt thrown or retracted by key from outside. Inside thumbturn cylinder retracts deadbolt, but cannot project it.

  • 626 Satin Chrome Finish
  • Less Cylinder (mortise cylinder sold separately)
  • 1″ stainless steel throw deadbolt
  • Anti-saw pin in bolt to prevent cut-through
  • Exceeds ANSI/BHMA Grade 1 standards


626 Satin Chrome


Handed – LH, RH


Schlage 30-001 Mortise Cylinder (sold separately)


ANSI 156.5, 1992, Grade 1. UL Listed.


Heavy Duty

Fire Rating

UL Listed


Stainless steel, 1” throw




1 1/8" x 3 5/8" (29 mm x 92 mm), no lip furnished with dust box , standard.

Case Size

4 7/16" x 3 5/8" x 1"

Armored Front

1-1/4" x 5 19/32" x 7/32"

Door Thickness
