Marks USA 175F Storeroom Lever Lock

Usually Ships: 1-2 Business Days
  • ANSI/BHMA Grade-2 certified
  • ANSI function: F86, storeroom
  • ADA compliant, 3-hour fire-rated

Available Options:

Clear

Marks USA 175F Lever Lockset, Storeroom Function, Grade-2, American Lever Design

The Grade 2 Survivor is supplied with 6-pin cylinders in Marks “C” keyway with 2 nickel-silver keys. The retractor is cast stainless steel with bronze roller bearings for ultra-high strength, smooth operation & long life. When locked, the Survivor’s clutch disengages the outside lever allowing it to turn freely without opening the latch. This reduces the torque applied to the outside lever. Other locksets with Rigid levers are prone to failure because of excessive torque.

ANSI Function F86 – Outside lever is always locked. Entrance by key only. Inside lever is always unlocked and always free for immediate egress.

  • High quality, longer lasting, lower maintenance design
  • Unique stainless steel “clutch” and bronze bearings dramatically reduce wear and abuse & eliminates lever droop
  • Competitively priced for exceptional value
  • Marks lifetime mechanical warranty
Brand

Finishes

US10BE (613e) Dark Oxidized Satin Bronze, Equivalent, US26D (626) Satin Chrome

Backset

2-3/8", 2-3/4"

Lock Function

Storeroom

Keyway

Schlage C Keyway

Lever Design

American

Usage

Medium Duty

ANSI Grade

Meets ANSI 156.2, Grade-2 Standards

Fire Rating

UL Listed up to 3 Hours

ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code

Latch

9/16" throw, deadlocking – 1-1/8" x 2-1/4" face

Strike

4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation

Handing

Non Handed – Completely Reversible

Door Thickness

1-5/8" to 1-7/8"

Warranty

Limited Lifetime Warranty
