HES 8300C Complete Pac Fire-Rated Electric Strike for Cylindrical Locks

The fire rated, concealed solution for cylindrical locksets

Works with cylindrical locksets and accommodates latchbolts up to 5/8″ throw

The 8300 Series Electric Strike is a fire rated, compact, high performance electric strike featuring a unique concealed design for use with cylindrical locksets. No cutting on the frame is required. Simply remove the existing ANSI strike plate, adjust the vertical alignment feature to the latchbolt centerline and install. Its strength is derived from a unique keeper pin locking design, enabling the 8300 to exceed the ratings of the frame, door and locking hardware. This unique electric strike is easy to install and complies with NFPA 80-07 guidelines for retrofit into fire rated frames. The 8300 accommodates latchbolts up to 5/8″ throw.

• No cutting on frame required
• Includes the 801 and 801A faceplates
• Vertical adjustability to accommodate door sag and misalignment
• Tamper-resistant
• Static strength 1,500 lbs
• Dynamic strength 70 ft-lbs
• Endurance 1 million cycles
• Field selectable fail secure/fail safe
• Non-handed

Certifications / Listings

• ANSI/BHMA A156.31, Grade 1
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 (6th Edition) listed
• RoHS compliant
• UL 10C fire rated, 3-hour single door (fail secure only)
• CAN/ULC-S104 fire door conformant
• NFPA-252 fire door compliant
• ASTM-E152 fire door compliant
• NFPA 80-07 compliant

Optional Features

• LBM – Latchbolt monitor (detects when latchbolt is in a locked state)
