HES 7000C Complete Pac Preload Solution Electric Strike for Cylindrical Locks and Rim Exit Devices


Usually Ships: 2-3 Days
  • For use with cylindrical locksets and rim exit devices
  • Installs in metal or wood frames
  • Ideal for applications with preload pressure

The dual, preload solution for cylindrical latchbolts and rim exit devices.

The 7000C is specially designed to address pre-loaded doors, and with in-frame horizontal adjustability, it works with cylindrical latchbolts up to 5/8″ throw and rim exit devices up to a 3/4″ throw.

Each Complete Pac conveniently pairs the reliability of an HES electric strike with the flexibility of multiple faceplates in a single simple package. The 7000C includes a 7000 strike body, the 791 faceplate an ANSI 4-7/8″ strike plate and the 792 faceplate for a 7-5/16″ strike plate.

Preload Capable

  • Preload release function allows smooth operation under loads on the door that often bind other electric strikes
  • Accommodates up to 15 pounds of preload (fail secure only)
  • Ideal for applications with preload caused by airconditioning pressure, changes in the weather, warped doors or doors with weather stripping

Robust and Reliable

  • ANSI/BHMA A156.31, Grade 1
  • Static strength 1,500 lbs, Dynamic strength 70 ft lbs
  • Endurance 1 million cycles

Versatile Design

  • Works with both cylindrical latchbolts up to 5/8″ throw and rim exit devices up to a 3/4″ throw
  • Field selectable fail secure/fail safe
  • Non-handed and includes plug in connector



630 Stainless Steel

ANSI Grade

ANSI/BHMA A156.31, Grade 1


Heavy Duty

Fire Rating



Dual voltage 12/24 VDC/VAC
