Yale 4607LN PB Entry Lever Lockset

Usually Ships: 2-3 Days
  • Medium Duty – Grade 2
  • For Interior or Exterior Use
  • ADA Compliant – 3 Hour Fire-Rated

Available Options:

  • Dark Bronze
  • Satin Chrome
Clear

ANSI Function F109 – Turn/Push button locking. Pushing and turning button locks outside lever requiring use of key until button is manually unlocked. Pushing button locks outside lever until unlocked with key or inside lever is turned.

  • Versatile: Field reversible handing and other product options offer flexibility in many commercial applications
  • Economical: Priced affordably to suit projects of all budgets
  • Secure: Quality security from a trusted brand for over 170 years
  • Strong & Reliable: ANSI/BHMA Grade 2 certified for long life and reliability
Brand

Lock Function

Entry (Entrance)

ANSI/BHMA Standard

Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, Grade 2

Cylinder & Keys

6-pin conventional, keyed different, with 2 keys

Keyway

Schlage C Keyway, Yale E1R (Para) Keyway

Backset

2-3/4" standard

Strike

4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation

Handing

Non-Handed

Lever Design

PB (Pacific Beach)

Door Thickness

1-3/8" to 1-3/4"

Fire Rating

UL-cUL fire rated up to 3 hours

ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code

Usage

Medium Duty

Finishes

613e Dark Oxidized Satin Bronze equivalent, 626 Satin Chrome

Latch

1/2” throw, deadlocking – 1-1/8" x 2-1/4" face
