Securitron M680E Series EcoMag Magnalock, 120lb Holding Force, Bracket Mount, 12/24VDC
Discover EcoMag Technology. When strength and aesthetics matter, the Securitron M680E EcoMag is the most advanced, sustainable electromagnetic lock available.
The M680E with EcoMag® technology from Securitron® delivers the same unsurpassed intelligence, style, and convenience as the previous M680 series, but with 80% reduction in energy consumption.
The M680E is intelligent, with built-in door prop sensing allowing the magnet to de-energize the coil when the door is held open for extended periods. The M680EBD offers built-in smart voltage sensing, integrated patented BondSTAT, tamper sensor as well as door position status monitoring. The aesthetics and design finishes of the EcoMag are refined enough for the most discriminating designer openings. It also offers the fastest, easiest, most secure installation of any bracket mount maglock with an updated strike plate mounting template. The optional integrated request to exit (REX) provides optimum coverage for detecting an approaching person so the door unlocks for egress.
- Strike plate mounting template provides the easiest install for out-swing doors
- LED Indicator shows the lock is secure, open, or has an incomplete bond
- Wire chamber anti-tamper switch
- Tamper Switch sends an alarm output if the cover is removed and is selectable to NO or NC
- Available integrated BondSTAT and Door Position Switch
- Autosensing dual voltage with microprocessor technology
- Adjustable automatic relock timer (0 to 30 seconds)
- Energy efficient, low power usage
- Size optimized for use with door closers
- MagnaCare® lifetime replacement, no-fault, no questions asked warranty
Models: M680EBD-628, M680EBD-606, M680EBD-613E, M680EBD-BSP, M680EBDX-628, M680EBDX-606, M680EBDX-613E, M680EBDX-BSP
613e Dark Oxidized Satin Bronze equivalent, BSP Black Suede Powder Coat, US4 (606) Satin Brass, US28 (628) Anodized Aluminum
Current 12v DC (mA) : 515, Current 24v DC (mA) : 325, Voltage : 12/24
Up to 1200 lbs.
BD: BondSTAT Monitor & Door Position Switch
ANSI/UL 10C Listed, 3 hour rated
