Pemko 305CR Standard Perimeter Gasketing Weatherstrip w/ EPDM Insert


Usually Ships: 5-10 Days
  • Use on door frames to seal top and sides of door
  • Seals against smoke, fire, air, and weather
  • 36″ x 84″ set, anodized aluminum w/ black insert

Pemko 305CR 36″ x 84″ screw-on perimeter weatherstrip set

Designed to be applied to the “stop” perimeter of the door frame. Includes an EPDM seal with aluminum framing. The seal compresses against the door, to create a tight weatherproof seal.

  • This perimeter gasketing is supplied with an EPDM insert
  • Stainless steel fasteners are standard
  • 36″ x 84″ set (2ea. 84″ jamb pieces and 1ea. 36″ header piece)
  • Full-Length; Field-Cut to Size

305CR: C – Clear Anodized Aluminum with Black Sponge EPDM insert


  • Air Infiltration Tested
  • BHMA Certified
  • Smoke Tested – UL1784
  • Fire Rated – UL10C – Positive Pressure
  • Underwriters Laboratory 4L10
  • GREENGUARD Gold Certified



C – Clear Anodized Aluminum


36" x 84"

Fire Rating

Fire Rated – UL10C – Positive Pressure

Gasket Type


Insert/Seal Type

Neoprene or EPDM
