HES 9800 Surface Mounted Electric Strike For Adams Rite Rim Exit Devices

Usually Ships: 2-3 Business Days
  • For use w/ Adams Rite 8700, 8800 and EX88 rim exit devices
  • Installs on aluminum, metal, or wood frames
  • Dual Voltage 12/24 VDC

Available Options:

Clear

Works with Adams Rite® Starwheel and Interlocking rim exit devices

The low-profile, surface-mounted electric strike designed to accommodate the Adams Rite 8700, 8800, and EX88 Series Rim Exit Devices.

The HES 9800 Series Electric Strike exceeds Grade 1 standards for strength and performance. All functions are performed within the 1/2″ thick strike body, which is protected by a sleek stainless steel cover to conceal the mounting screws and provide the most aesthetic appearance. All while being field selectable for fail secure or fail safe operation, and dual voltage, 12 or 24 VDC.1/16″ and 1/8″ spacer plates are provided to accommodate varying door gaps. Simply place the electric strike on the surface of the frame, align it with the Starwheel or Interlocking latchbolt, and install.

  • Compatible with Adams Rite 8700, 8800 and EX88 Series Rim Exit Devices
  • Endurance 1 million cycles
  • Installs on aluminum, hollow metal and wood frames (wood screws not provided)
  • Field selectable fail safe/fail secure
  • Dual voltage 12 or 24 VDC
  • Non-handed

Certifications / Listings

  • ANSI/BHMA A156.31, Grade 1
  • UL 1034 burglary-resistant listed and suitable for outdoor use
  • UL 294 listed
  • UL 305 listed
  • RoHS compliant

Brand

Finishes

606 Satin Brass, 613e Dark Oxidized Satin Bronze equivalent, 628E Satin Aluminum Powder Coat, 630 Satin Stainless Steel, BSP Black Suede Powder Coat

Usage

Heavy Duty

ANSI Grade

ANSI/BHMA A156.31, Grade 1

Fire Rating

Non-Fire-Rated

Voltage

Dual voltage 12 or 24 VDC
