HES 8000C Complete Pac Electric Strike for Cylindrical Locks

Usually Ships: 2-3 Business Days

For use with cylindrical locksets, up to 5/8″ throw
Installs in metal or wood frames
Easy to install, No cutting on frame required

Available Options:

Option

Clear

Quantity:

The concealed electric strike solution for cylindrical locksets

Works with cylindrical locksets and accommodates latchbolts up to 5/8″ throw

The 8000 series is a compact, high performance electric strike featuring a unique concealed design for use with cylindrical locksets. No cutting on the frame is required. Simply remove the existing strike plate, adjust the vertical alignment feature to the latchbolt centerline, and install. Its strength is derived from a unique keeper pin locking design, enabling the 8000 to exceed the ratings of the frame, door and locking hardware. This field selectable fail secure/fail safe unit is easy to install and accommodates latchbolts up to 5/8″ throw.

No cutting on frame required
Vertical adjustability to accommodate door sag and misalignment
Tamper-resistant
Static strength 1,500 lbs
Dynamic strength 70 ft-lbs
Endurance 1 million cycles
Field selectable fail secure/fail safe
Non-handed

Certifications / Listings

ANSI/BHMA A156.31, Grade 1
UL 1034 burglary-resistant listed and suitable for outdoor use
UL 294 (6th Edition) listed
RoHS compliant

Optional Features

LBM – Latchbolt monitor (detects when latchbolt is in a locked state)

Brand	HES
Finishes	630 Satin Stainless Steel
ANSI Grade	ANSI/BHMA A156.31, Grade 1
Usage	Standard Duty
Fire Rating	Non-Fire-Rated
Voltage	Dual voltage 12/24 VDC/VAC
