Dormakaba 9700 BB Narrow Stile Rim Exit Device

$1,070.55

This item ships FREE! Usually Ships: 2-3 Business Days
  • Heavy-Duty – ANSI/BHMA Grade-1 Certified
  • Exit only model (trim sold separately)
  • Min. stile 2-7/16″ (2-9/16″ with trim)

Dorma 9700BB 630 Grade 1 Rim Exit Device, Narrow Stile Pushpad, 36″ Length, Satin Stainless Steel Finish

The 9700 Series narrow stile exit device with a shortened touchbar is the ultimate solution when narrow stile doors require an exit device. The heavy-duty cast chassis design permits installation on narrow stile doors where a standard device may not fit. The smooth projection touchbar assembly minimizes catch hazards.

  • Exit Only (Dorma outside exit device trim sold separately)
  • Ideal for aluminum storefront doors
  • Device fits stiles as narrow as 2-7/16″ (2-9/16″ with trim)
  • Size BB = 36″
  • 630 stainless steel finish
Brand

Length

Size BB – 27" to 36"

Finishes

630 Satin Stainless Steel

Stile Type

Narrow

Usage

Heavy Duty

ANSI/BHMA Standard

Certified/listed to ANSI/BHMA 156.3, Grade 1 for exit devices

Fire Rating

Non-Fire-Rated

Strike

430 Standard
