PDQ 9910 Electric Strike for Rim Exit Devices

$432.28
Usually Ships:  3-5 Business Days
  • For use with rim exit devices
  • Accommodates 1/2" to 3/4" latch projection
  • 500mA Field-Selectable 12/24VDC & 12-24VAC

Product Overview

PDQ 9910 Surface-Mounted Electric Strike for 6300/6400 Rim Exit Devices, 500mA Field-Selectable 12/24VDC & 12-24VAC (Max at 12VDC), Fail-Secure, Fire-Rated

PDQ’s 99100 electric door strike offers strong security for high-traffic areas to improve your buildings access control without having to sacrifice on quality. This electric strike is designed to work with our 6300 and 6400 rim exit devices.  Manufactured for durability, and to be easily installed, this electric strike is a great solution to pair with your rim exit device.

  • 500mA Field-Selectable 12/24VDC & 12-24VAC (Max at 12VDC)
  • Completely surface-mounted
  • Accommodates 1/2” to 3/4” (13mm–19mm) latch projection
  • Mounting spacer included to provide enhanced latch engagement
  • Stainless steel ensures superior strength and creates a sleek aesthetic design
  • Horizontal adjustment ensures proper latch positioning to compensate for door misalignment – up to 1/4” (6.4mm)
  • Conventional keeper design
  • Plug-in wire connectors
  • Lockdown holes for secure mount
  • HEX socket head cap screws for added support
  • Installation tool included
  • Non-handed
Brand

Finishes

US32D (630) Satin Stainless Steel

Usage

Heavy Duty

Current

500mA Field-Selectable 12/24VDC & 12-24VAC (Max at 12VDC)

Fail Secure / Fail Safe

Fail Secure (standard)

Fire-Rating

UL 10C (3-Hour)

Lock Type Compatibility

Rim Exit Device

Warranty

5 Year
