Schlage

Schlage B680 Door Bolt, One-Sided Deadbolt, Turn Inside x No Outside Trim

$136.45
Usually Ships:  1-2 Business Days
  • ANSI/BHMA A156.5 Grade 1 certified
  • ANSI Function E0191
  • Turn inside x no trim outside

Available Options:

Clear

Product Overview

Schlage B680 Grade 1 Door Bolt, Turn Unit Inside x No Outside Trim, 2-3/4" Backset

ANSI Function: E0191 – Deadbolt thrown or retracted by thumbturn inside. No trim on inside. 1-1/2" bore only.

  • Schlage’s toughest and highest grade heavy-duty Grade 1 commercial deadbolt
  • 1″ throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
  • Metal shield protects bolt from ice-pick attack through the door
  • Hardened steel ball-bearings protect mounting bolts from drill attack
  • Meets or exceeds ANSI/BHMA Grade 1 operational and security standards
  • UL listed for 3-hour fire door as auxiliary lock
Brand

Finishes

626 Satin Chrome, 605 Bright Brass, 606 Satin Brass, 622 Matte Black, 612 Satin Bronze, 613 Oil Rubbed Bronze, 625 Bright Chrome, 643e Aged Bronze, 619 Satin Nickel, 609 Antique Brass

Deadbolt Type

Turn Inside Only

ANSI Function

E0191

ANSI/BHMA Standard

ANSI A156.36, Grade 1

ANSI Grade

ANSI Grade 1

Usage

Heavy Duty

Bolt

1" throw bolt, 1-1/8" x 2-1/4" square corner face plate

Backset

2-3/4"

Strike

1-1/8” x 2-3/4“ square corner

Fire-Rating

UL Listed for “A” Label 3 Hour Fire Doors

Door Thickness

1-3/4" to 2"
