Schlage B660P Single Cylinder Deadbolt

Usually Ships: 1-2 Business Days
  • ANSI/BHMA A156.5 Grade 1 certified
  • Features a thick, anti-saw hardened steel bolt with anti-pry
  • Single cylinder x inside thumbturn

Available Options:
Clear

Product Overview

Schlage B660P Grade 1 Single Cylinder Deadbolt, Conventional Cylinder, 2-3/4″ Backset

Schlage commercial grade 1 deadbolts are designed for security, durability, and beauty. They feature a thick, anti-saw hardened steel bolt with anti-pry, anti-wrench and other protections to make it one tough lock.

ANSI Function E0151: Deadbolt thrown or retracted by key outside or thumbturn inside

  • Schlage’s toughest and highest grade heavy-duty Grade 1 commercial deadbolt
  • 1″ throw, high-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
  • Metal shield protects bolt from ice-pick attack through the door
  • Hardened steel ball-bearings protect mounting bolts from drill attack
  • Meets or exceeds ANSI/BHMA Grade 1 operational and security standards
  • UL listed for 3-hour fire door as auxiliary lock

Brand

Finishes

605 Bright Brass, 606 Satin Brass, 609 Antique Brass, 612 Satin Bronze, 613 Oil Rubbed Bronze, 619 Satin Nickel, 622 Matte Black, 625 Bright Chrome, 626 Satin Chrome, 643e Aged Bronze
Keyway

Schlage C Keyway, Schlage E Keyway, Schlage S123 Keyway
Deadbolt Type

Single Cylinder
ANSI Function

E0151
ANSI/BHMA Standard

ANSI A156.36, Grade 1
ANSI Grade

ANSI Grade 1
Usage

Heavy Duty
Cylinder & Keys

6-pin conventional, keyed different, with 2 keys
Bolt

1" throw bolt, 1-1/8" x 2-1/4" square corner face plate
Backset

2-3/4"
Strike

1-1/8” x 2-3/4“ square corner
Fire Rating

UL Listed for “A” Label 3 Hour Fire Doors
ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code
Door Thickness

1-3/8" to 1-3/4"
