Product Overview
McKinney TA2798 4-1/2" x 6" Full Mortise Steel Five Knuckle Standard Weight Bearing Hinge, Wide Throw
The TA2798 (steel) wide throw five knuckle standard weight full mortise hinges are utilized where a door is recessed from the face of the frame, and is recommended for standard weight and medium frequency doors.
Features
- Utilized where a door is recessed from the face of the frame
- Allows door to open around a large reveal
Benefits
- Provides more clearance behind a door that opens up to 180 degrees
- Prevents binding or interference with trim installed on the face of the frame or wall
| Brand | |
|---|---|
| Finishes |
652 Satin Chrome, 600 Prime Coat, 633 Satin Brass, 640 Oil Rubbed Bronze, 651 Bright Chrome, 632 Bright Brass, 639 Satin Bronze |
| Hinge Type |
Full Mortise |
| Special Feature |
Wide Throw Hinge |
| Size |
4.5" x 6" |
| Knuckles |
Five |
| Bearings |
Oil Impregnated Bearing |
| Gauge |
0 .134 |
| Usage |
Medium Duty |
| ANSI/BHMA Standard |
Meets ANSI/BHMA A156 .1 |
| Fire-Rating |
Certified to meet UL standards (3hr) |
| Fasteners |
Packed with wood and metal screws |
