Dormakaba

Dormakaba 9100 Concealed Vertical Rod Exit Device

$1,510.45
Usually Ships:  1-2 Business Days
  • Heavy Duty - ANSI/BHMA Grade-1 Certified
  • Designed for high-use and abuse applications
  • Exit only model (trim sold separately)

Available Options:

Clear

Product Overview

Dormakaba 9100 Grade 1 Concealed Vertical Rod Exit Device, Wide Stile Pushpad

The 9000 Series heavy-duty exit device provides superior durability while the smooth reduced projection touchbar assembly minimizes catch hazards. This premium exit device is for high-impact applications such as schools, universities, and other institutional or commercial buildings.

The 9100 Concealed Vertical Rod is an excellent choice where barrierfree codes, aesthetics, or the potential for vandalism require concealment of the vertical rod. They are panic and fire-listed (three-hour steel fire door applications) and feature a simplified adjustment mechanism that provides ease of installation and reduced service requirements.

Exit Only (Dormakaba outside exit device trim sold separately)

  • Size B = 3'0" x 7'0" or Size A = 4'0" x 7'0" (ETR Extension Rod Kit available for 8'0" to 10'0" doors)
  • Devices fit standard 1-3/4”- 2-1/4” thick doors
  • UL Listed Panic Hardware

Brand

Finishes

630 Satin Stainless Steel, 695 Dark Bronze (Powder Coated), 693 Black (Powder Coated)

Length

Size B - 28" to 36", Size A - 34" to 48"

Door Height

7'0" (Standard)

ANSI/BHMA Standard

Certified/listed to ANSI/BHMA 156.3, Grade 1 for exit devices

Fire-Rating

Non Fire-Rated

Usage

Heavy Duty

Strike

418/439

Stile Type

Wide (Standard)

Stile

4-1/2 " minimum

Handing

Non Handed – Completely Reversible

Buy American Act Compliance

Meets Buy American Act - Made in USA
