Detex SRN5W Weatherized Siren, Remote Horn

Detex SRN5W Weatherized Siren, No Lettering, 12/24VDC, 4in x 4in Enclosure, Conduit Fittings Included – Gray

For added security in your facility, Detex offers a remote horn that can easily be mounted on any surface. When the environment is noisy or an exterior sounder is needed, the SRN5W remote horn can draw attention to possible breaches in your security. The SRN5W can be used indoors as well as exterior environments.

Features:

• Can be used with other Detex products to extend attention area
• Weatherized for indoor and outdoor installations
• Easy 4-wire hookups speed installation (2 power wires/2 relay wires)
• General signaling certification allows use in typical door hardware applications (not fire alarm)
• Drain holes on face plate to allow water/moisture to escape
• 4″ x 4″ enclosure allows ample room for wires and connections to be done quickly and easily
• Conduit fittings included
• 4″ x 4″ enclosure – surface mount
• Die cast construction and design provides protection
• Weatherized electronics for use indoors and outdoors
• Gasketing on face
• Relay with wires activates when siren is sounding
• LED indicates relay output is activated and horn is sounding
• One page of easy-to-follow instructions
• Side conduit input

Specifications:

• Gray finish
• 12VDC or 24VDC – auto sensing
• 12VDC @ 70mA
• 24VDC @ 70mA
• 100dB siren
• Three threaded plugs and one conduit fitting included.
• 2 wires for dry contact remote output activation: gray – normally closed; yellow – normally open; brown – common.
• 2 wires for 12/24VDC input power: black – ground; red – 12VDC or 24VDC.
