Detex EAX-500 Battery Powered Door Exit Alarm

Usually Ships: 1-2 Business Days

Surface mounted exit alarm – 100 dB piezo alarm
Alarm can only be silenced by control key
Requires mortise cylinder (sold separately)

Available Options:

Finish

Clear

Subtotal
Options
Total

Quantity:

Detex EAX-500 Exit Alarm, Surface Mount, Battery Powered

The EAX-500 is designed for applications that require a battery-powered alarm on secured doors. The alarm, with approximately 100dB, will sound when someone attempts an unauthorized exit. The redesigned shape and smaller size of the EAX-500 makes it the choice for quick and easy installations on emergency exit and restricted doors.

Requires Mortise Cylinder (Sold Separately)
Low cost, self-contained door alarm with piezo horn that sounds to warn unauthorized use of a door or gate
Tapered cover allows for installation on narrow stile doors
Intelligent circuit senses the external magnet location automatically and sets the correct door handing
Alarm can only be silenced by proper control key
Secure, tamper resistant housing
9VDC battery operated with Low Battery Alert
LED visual and audible arming indicators

Brand	Detex
Finishes	Black (BK), Gray (G)
Power	9VDC battery operated
ANSI/BHMA Standard	ANSI/BHMA A156.29
Fasteners	Machine and Self-Drilling Screws
Mounting	Surface Mount
Cylinder	Mortise Cylinder Required with Standard Cam (Sold Separately)
