Accentra (Formerly Yale)

Accentra (Formerly Yale) 2100 x 217F Panic Rim Exit Device with Nightlatch Pull Trim

$249.29
Usually Ships:  1-2 Business Days
  • ANSI/BHMA Grade-1 Certified
  • ANSI Function 03 (nightlatch)
  • Includes 217F pull (cylinder sold separately)

Available Options:

Clear

Product Overview

Accentra (formerly Yale) 2100/2100F Economy Rim Exit Device, 217F Nightlatch Pull Trim

Providing a higher standard of ANSI/BHMA Grade 1 performance, the 2100 Series Exit Device is the right choice for meeting the rigors of everyday use. The 2100 Series is a perfect fit for both back of house and prominent openings in office buildings, retail, and a long list of other facilities that require both performance and style.

  • ANSI Function 03 – Key retracts latch bolt, Nightlatch Access by Key
  • Tough: Sturdy construction is ideal for meeting the rigors of demanding industry environments
  • Economical: Works for many building projects, regardless of budget
  • Strong & Durable: ANSI/BHMA Grade 1 Certification ensures long life and reliability

Yale 217F Nightlatch Pull Trim, Less Cylinder

  • ANSI Function: 03
  • 1-3/4″ door standard
  • Rim cylinder required (sold separately)
  • Plate Dimensions: 3-1/2″ x 3-3/4″ x 3/32″
  • Finger Pull Dimensions: 3-1/2″ x 6-3/4″ x 1/8″
Brand

Length

36" (for 30" to 36" Doors), 48" (for 42" to 48" Doors)

Finishes

689 Aluminum (Powder Coated)

Includes Trim

Yes

Trim

217F

ANSI/BHMA Standard

Certified ANSI/BHMA A156.3, Grade 1

Usage

Medium Duty

Stile Type

Wide (Standard)

Fire-Rating

2100: Non-Rated - 2100F: 3 Hour Fire-Rated

Handing

Non Handed – Completely Reversible

Minimum Stile Width

4-1/2"

Projections

2-1/2" active, 1-3/4" dogged

Latchbolt

3/4" deadlocking stainless steel pullman-type

Strike

757F, 793 optional (double door application, panic only)

Dogging Feature

Hex key dogging standard on non-fired-rated devices

Fasteners

Machine screws and wood door fasteners standard for panic hardware. Sex nuts and bolts supplied standard for fire exit hardware

Door Applications

1-3/4" Metal, wood or composite doors

Warranty

3 Year
